Glass Depth Cartridge, 0.30 Micron Rating, GGD-30, General Grade
Glass Depth Cartridge, 0.30 Micron Rating, GGD-30, General Grade
Write a Review

Glass Depth Cartridge, 0.30 Micron Rating, GGD-30, General Grade

Part Number: GGD-30
Your Price: $244.28
Retail Price:$305.35
Your Savings:$61.07(20%)
Glass Depth Cartridge, 0.30 Micron Rating, GGD-30, General Grade
Call for Stock Level
Feature: 2055

Choose Options

*
*
*
Glass Depth Cartridge, 0.30 Micron Rating, GGD-30, General Grade

GGD grade Fiber Glass Depth cartridges are designed for general purpose use wherever a cost effective pleated Fiber Glass Depth filter is required. 99% efficiencies at the rated pore size and designed to hold the maximum amount of filter media that can be completely and effectively utilized in a cartridge. GGD cartridges are flushed with 17+ megohm-cm water to remove potential extraneous manufacturing debris. These cartridge modules are also individually tested.

Maximum Operating Parameters

• Micron Rating: 0.30 Micron
• Maximum Operating Temperature*: 180°F (82°C) at 10 psid in water
• Forward Differential Pressure: 50 psi (3.4 bar) at 20°C
• Reverse Differential Pressure: 40 psi (2.7 bar) at 20°C
• Recommended Changeout Pressure: 35 psid (2.4 psid)

Construction Materials

• Filtration Media:  Fiber Glass
• Filtration Media Support: Polyester
• End Caps: Polypropylene
• Center Core: Polypropylene
• Outer Support Cage: Polypropylene
• Sealing Method: Thermal Bonding

Dimensions

• Length: 5 to 40" (12.7 101.6 cm) nominal
• Outside Diameter: 2.75" (7.0 cm) nominal
• Surface Area: 6.8 ft2 (0.63 m2) Per 10" length

Applications
Pre Filtration of:

• Wine Clarification                    • Soft Drinks
• Beverage Clarification              • Bottled Water
• Cosmetics                                 • Process Water
• Syrups                                      • Air
